INTRODUCTION OF OUR SERVICES AND PROJECT

Fabtech design services is a service provider company specializing in 3D modelling structural / miscellaneous steel detailing and stair connection design. Global reach, adoption of leading-edge technology, software and innovative processes keep Fabtech challenged and productive for the benefit of their customers. Fabtech prides itself in quality, timely delivery of projects and open communication with clients. Fabtech Design services client’s success, represents our success.

Show More

SERVICES WE OFFER

LIGHT/HEAVY RESIDENTIAL, INDUSTRIAL AND COMMERCIAL STRUCTURAL STEEL OR MISC. DETALING PROJECTS

  • Anchor bolt setting plan, Embed layout plan, and Erection plan for field use.
  • Column, beam, brace , truss, ladder, canopy
  • stair,  assambly drawings and Part drawing for shop use.
  • Advance Bill of Material and such as all type report files like XML, EJE, KISS, CNC, NC, DXF, Field Bolt List, Assembly lists, Part lists, Connection Sketches and tekla model information etc.

OUR WORKING SYSTEM



  • CLIENT COMMUNICATION
  • PROJECT QUOTATION
  • START THE PROJECT
  • STUDY THE DESIGN DRAWING
  • PREPARE THE PRE-DETAILING CHECK LIST FOR KICK OFF MEETING
  • MAPOWER PLANNING
  • RFI (Request for missing information)
  • 3D MODELING & 2D DETAILING
  • CHECKING MODEL & DRAWINGS
  • SUBMISSION (FOR APPROVAL)
  • FOLLOWING BFA COMMENTS
  • SUBMISSION (FOR FABRICATION)
